Parameter Lists
Par. No. # Parameter description
30-07 Wobble Sequence Time
30-08 Wobble Up/ Down Time
30-09 Wobble Random Function
30-10 Wobble Ratio
30-11 Wobble Random Ratio Max.
30-12 Wobble Random Ratio Min.
30-19 Wobble Delta Freq. Scaled
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
High Starting Torque Current
30-21 [%]
30-22 Locked Rotor Protection
Locked Rotor Detection Time
30-23 [s]
30-8* Compatibility (I)
30-80 d-axis Inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
Process PID Proportional
30-84 Gain
4.1.23 32-** MCO Basic Settings
Par. No. # Parameter description
32-0* Encoder 2
32-00 Incremental Signal Type
32-01 Incremental Resolution
32-02 Absolute Protocol
32-03 Absolute Resolution
Absolute Encoder Baudrate
32-04 X55
Absolute Encoder Data
32-05 Length
Absolute Encoder Clock
32-06 Frequency
Absolute Encoder Clock
32-07 Generation
Absolute Encoder Cable
32-08 Length
32-09 Encoder Monitoring
32-10 Rotational Direction
32-11 User Unit Denominator
32-12 User Unit Numerator
32-13 Enc.2 Control
32-14 Enc.2 node ID
32-15 Enc.2 CAN guard
32-3* Encoder 1
32-30 Incremental Signal Type
32-31 Incremental Resolution
®
VLT AutomationDrive FC 301/302 Programming Guide
Default value 4-set-up
10 s All set-ups
5 s All set-ups
[0] Off All set-ups
1 N/A All set-ups
10 N/A All set-ups
0.1 N/A All set-ups
0 Hz All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit All set-ups
0.100 N/A All set-ups
Default value 4-set-up
[1] RS422 (5V TTL) 2 set-ups
1024 N/A 2 set-ups
[0] None 2 set-ups
8192 N/A 2 set-ups
[4] 9600 All set-ups
25 N/A 2 set-ups
262 kHz 2 set-ups
[1] On 2 set-ups
0 m 2 set-ups
[0] Off 2 set-ups
[1] No action 2 set-ups
1 N/A 2 set-ups
1 N/A 2 set-ups
[0] No soft changing 2 set-ups
127 N/A 2 set-ups
[0] Off 2 set-ups
[1] RS422 (5V TTL) 2 set-ups
1024 N/A 2 set-ups
