Danfoss VLT AutomationDrive FC 302 Programming Manual page 164

Parameter Descriptions
16-57 Feedback [RPM]
Range:
0 RPM [-30000 -
*
30000
RPM]
3 3
3.17.4 16-6* Inputs and Outputs
16-60 Digital Input
Range: Function:
0 [0 - View the signal states from the active digital inputs.
1023 ] Example: Input 18 corresponds to bit no. 5, '0' = no
*
signal, '1' = connected signal. Bit 6 works in the
opposite way, on = '0', off = '1' (safe stop input).
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bit 10-63
16-61 Terminal 53 Switch Setting
Option:
[0] Current
[1] Voltage
162
Function:
Read-out parameter where the actual
motor RPM from the feed-back source can
be read in both closed loop and open
loop. The feed-back source is selected by
parameter 7-00 Speed PID Feedback Source.
Digital input term. 33
Digital input term. 32
Digital input term. 29
Digital input term. 27
Digital input term. 19
Digital input term. 18
Digital input term. 37
Digital input GP I/O term. X30/4
Digital input GP I/O term. X30/3
Digital input GP I/O term. X30/2
Reserved for future terminals
Table 3.25 Active Digital Inputs
Illustration 3.60 Relay Settings
Function:
View the setting of input terminal 53.
®
VLT AutomationDrive FC 301/302 Programming Guide
16-62 Analog Input 53
Range:
0 [-20 - 20 ]
*
16-63 Terminal 54 Switch Setting
Option:
[0] Current
[1] Voltage
16-64 Analog Input 54
Range:
0 [-20 - 20 ]
*
16-65 Analog Output 42 [mA]
Range:
0 [0 - 30 ] View the actual value at output 42 in mA. The
*
16-66 Digital Output [bin]
Range:
0 [0 - 15 ]
*
16-67 Pulse Input #29 [Hz]
Range:
0 [0 - 130000 ] View the actual frequency rate on terminal
*
16-68 Freq. Input #33 [Hz]
Range:
0 [0 - 130000 ] View the actual value of the frequency
*
16-69 Pulse Output #27 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses applied to
*
16-70 Pulse Output #29 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses at terminal 29
*
MG33MI02 - Rev. 2013-11-20
Function:
View the actual value at input 53.
Function:
View the setting of input terminal 54.
Function:
View the actual value at input 54.
Function:
value shown reflects the selection in 6-50 Terminal
42 Output.
Function:
View the binary value of all digital outputs.
Function:
29.
Function:
applied at terminal 33 as an impulse input.
Function:
terminal 27 in digital output mode.
Function:
in digital output mode.
This parameter is available for FC 302 only.
