● However, as the axis continues to rotate, the standstill tolerance window is violated (time
axis approx. 600 ms)
● STOP B is initiated (see bit "SS1 active")
● The drive is braked to a standstill
● Standstill is reached (time axis approx. 650 ms)
● STOP A (as follow-up response to STOP B) is activated (see bit "STO active"); at this
point the speed falls below the shutdown speed SS1 (p9560) (drops below the shutdown
speed SS1 before SS1 timer (p9556) has expired).
Not e
Time differences through internal c alculations
Small time differences (of the order of two to three safety cycles (here up to 6 ms)) are
caused by internal calculations and do not present a problem.
SDI positive/negative with encoder and stop response "STOP E"
N o .
N o te:
The acceptance test must be individually performed for each configured control and for both directions of rotation.
Control can be realized without selection via TM54F, onboard terminals (CU310-2) or via PROFIsafe.
1.
Initial state
Drive in the "Ready" state (p0010 = 0)
Safety Integrated Extended Functions enabled (p9601.2 = 1)
Safety functions enabled (p9501.0 = 1)
Safety configured with encoder (p9506 = 0 or p9506 = 2)
For "Motion monitoring without selection (Page 205)":
- "SDI positive or negative" activated (p9512.12 = 1 or p9512.13 = 1)
SDI enabled (p9501.17 = 1)
SDI positive deselected (r9720.12 = 1) and SDI negative deselected (r9720.13 = 1)
Note: The parameterized SDI monitoring is already active for motion monitoring with-
out selection.
No Safety faults and alarms (r0945[0...7], r2122[0...7], r9747[0...7]) at the drive and
TM54F (if used); see note "Non-critical alarms" at the beginning of Section "Ac-
ceptance test."
2.
It may be necessary to take measures in the higher-level controller to be able to exceed the SDI tolerance.
Note that the internal limits (r9733[0], r9733[1] and r9733[2]) are removed by selecting "Start acceptance test".
3.
Configure and activate trace recording
Trigger: Trigger on variable - bit pattern (r9722.7 = 0)
Record the following values: r9713[0], r9721, r9722
Safety Integrated
Function Manual, (FHS), 07/2016, 6SL3097-4AR00-0BP6
D e scri p ti o n
A.3 Acceptance tests (recommendations)
Appendix
Sta tu s
467
