48 Chapter 2 Testing Video Displays
Note: The list of images that appears when you press the Content key may be a
filtered or abbreviated list. You may have disabled certain image catalogs, preventing
the images in those catalogs from appearing on the Content list. For more information
about image catalogs, see
3. Choose an image by pressing the adjacent soft key.
The table below provides a summary of display characteristics and the images used to
evaluate them. For details on the images and display attributes, see Appendix B,
Reference."
Display type Display test
Analog CRT Geometry
(pin and barrel, linearity)
Focus
Photometry (chrominance,
contrast, levels)
Luminance
Gamma correction
Resolution
Pulse (CE SDTV)
Centering
Voltage Regulation
Electromagnetic
Interference
"Creating image catalogs" on page 229.
Recommended images
Static images
Hatch (TVHatch,
clesL, Geom_1 -
Focus_@6, Focus_@7, Focus_@8,
Focus_@9,
Text_12T, Text_16
Flat, Flat07, Flat13, Flat20, Flat27, Flat33,
Flat40, Flat47, Flat53, Flat60, Flat67, Flat73,
Flat80, Flat87, Flat93, FlatGray, Flat_01,
Flat_02, Flat_03, Flat_04, Flat_05, Flat_06,
Flat_07, Flat_08, Flat_09, Flat_10, Flat_11,
Flat_12, Flat_13, Flat_14, Flat_15,
Ramp_B, Ramp_G, and
ColorBar, SMPTEbar,
(TV formats only)
SMPTE133
Grays11, Grays16, Grays32, Grays64
SMPTE133
BurstTCE,
Grill_15, Grill_22, Grill_33, Grill_44
PulseBar
Outline0, Outline1, Outline2, Outline3
Regulate
EMITest1, EMITest2, EMITest3, EMITest4,
EMITest5
Hatch_16, Hatch_20),
Geom_5, SMPTE133
Text_9, Text_9T, Text_11,
Flat_16,
Ramp_R,
TVBar100 & TVBar_75
(grayscale), Grays5, Grays9,
(checkerbox)
Burst (TV formats only), Grill_11,
"Image
Cir-
