882 Video Test Instrument User Guide (Rev A.35)
ISUB 1 // Enables sub images
IVER 1 // Specifies the first image version
IMGU // Activates the image version
5. To verify proper HDMI audio handling, check the following on the HDMI display:
• Audio is output from the proper channels (left, right, or both).
• When amplitude is adjusted, the volume is subsequently changed.
• When frequency is adjusted, the pitch is subsequently changed.
6. When testing is complete, disable image versions by pressing the Options key and
choosing More until a - appears next to it.
Alternatively, to disable image versions using the command line interface, enter the
following command:
ISUB 0 // Disables sub images
7. Press the Content key and choose the AudioRAT image to test the sampling rate.
The AudioRAT image appears on the connected HDMI display. The image shows the
current settings for the HDMI audio output. Note that the sampling rate image
(AudioRAT) applies to all audio channel.
Alternatively, to select the AudioRAT image using the command line interface, enter the
following commands:
IMGP /tffs0/Library/Images
IMGL AUDIORAT
IMGU
8. Enable and view image versions for the AudioRAT image as follows:
a. Press the Options key. The following menu appears on the 882's display:
-More
-NoGamma
-Noise
b. Choose the More item by pressing the adjacent soft key until a + and Rendition
appears next to the item.
+More Rendition: 000
-NoGamma
-Noise
c. Press the + and - keys to advance through the image versions to change the audio
sampling rate.
Alternatively, to enable and view an image version using the command line interface,
enter the following commands:
ISUB 1 // Enables sub images
// Set image path to 882 memory
// Loads the AudioRAT image
// Activates the AudioRAT image
Red+
Green+
Blue+
Red+
Green+
Blue+
