184 Chapter 5 Working with Formats
Heading Field
Extended From
Extended Apert.
Bars
Description / Function
Enables you to set the mapping type for mapping
Content Apert. CXAR-shaped image content into the extended
Map EXAR-shaped aperture.
Parameter: EXCX
Signal from Enables you to set the mapping type for mapping
EXAR-shaped image content into the SXAR-shaped
signal interface.
Map
Parameter: SXEX
Left Sets the left side letterbox bars in pixels.
Right Sets the right side letterbox bars in pixels.
Top Sets the top letterbox bars in pixels.
Bottom Sets the bottom letterbox bars in pixels.
