882 Video Test Instrument User Guide (Rev A.35)
Parameter
3D
3D Additional
4K x 2K
Basic Audio
Connector Type A
Write Protected
HDMI 1.3B CTS
Deep Color
DC 30 Bit
DC 36 Bit
DC 48 Bit
DC YCbCr 4:4:4
xvYCC
Exceeds 165MHz
1920x1080p/60 16:9
1920x1080p/50 16:9
Explanation
Does the sink support 3D formats. The values are + for
yes and - for no.
Does the sink support 3D additional formats in addition
to the mandatory 3D formats. The values are + for yes
and - for no.
Does the sink support 4K x 2K formats. The values are
+ for yes and - for no.
Indicates whether the sink supports basic audio. The
values are + for yes and - for no.
Indicates whether the sink under test input connector is
a Type A connector.
Indicates whether the EDID of the sink under test is
write protected.
Indicates whether to test sink against HDMI Compliance
Test Specification (CTS) 1.3b or 1.2a. The values are +
for 1.3b or - for 1.2a.
Indicates whether the sink under test supports deep
color. The values are + for yes and - for no.
Indicates whether the sink under test supports deep
color at 30 bits per pixel. The values are + for yes and -
for no.
Indicates whether the sink under test supports deep
color at 36 bits per pixel. The values are + for yes and -
for no.
Indicates whether the sink under test supports deep
color at 48 bits per pixel. The values are + for yes and -
for no.
Indicates whether the sink under test supports deep
color in YCbCr 4:4:4. The values are + for yes and - for
no.
Indicates whether the sink under test supports
xvYCC601 or xvYCC709. The values are + for yes and
- for no.
Indicates whether the sink under test supports any
video format/color mode with a TMDS clock frequency
above 165MHz. The values are + for yes and - for no.
Indicates whether the sink under test supports the
1080p60 format at 16:9 aspect ratio. The values are +
for yes and - for no.
Indicates whether the sink under test supports the
1080p50 format at 16:9 aspect ratio. The values are +
for yes and - for no.
