882 Video Test Instrument User Guide (Rev A.35)
3. Press the Options key. The following information appears on the 882's display.
-EDID Formats
+HP Bypass
-Emulate
4. Choose the EDID Formats item by pressing the adjacent soft key. A + appears next to
EDID Formats, indicating it is enabled.
The 882 loads the Source list with formats supported by the connected display
(hot-plug formats read via EDID structure of attached display).
5. Press the Content key. The following information appears on the 882's display.
Acer1
Acer3
Acer5
Acer7
6. Select an image suitable for testing the display type (such as Master) by pressing the
soft key adjacent to the image.
Alternatively, to select the image using the command line interface, enter the following
command:
IMGL Master
IMGU
7. Press the Source key and select a format beginning with SVD by pressing the adjacent
soft key.
8. On display under test, verify format displays image properly.
9. Repeat steps 7 and 8 to test each SVD format.
Note: Always make sure the 882 is using the lastest firmware.
CDF
Acer2
Acer4
Acer6
Acer8
