120 Chapter 14 Using Special Sync Output
2. Choose the Probe item by pressing the adjacent soft key. The current probe settings
appear on the generator's display as shown below:
Left P:0000
Right X:0000
Up L:0000
Down Y:0000
3. Press the Settings key to access the setting for the probe pulse width. The following
appears on the generator's display:
Probe Tool
Probe Width
PSPW
<- 136
4. Set the probe width as follows
a. Position the blinking cursor on the digit you want to change. To do this, press the
soft key adjacent to the arrow by the width value to move the cursor left or right until
it appears on the digit you want to change.
b. Adjust the value of the digit up or down by pressing the + or - keys. Repeat for each
you want to change.
5. To save the changes, press the Enter (Options) key. The following choices appear on
the generator's display:
Apply Settings?
Yes
To save the changes, choose the Yes item by pressing the adjacent soft key.
To exit without saving the changes, choose the No item.
To return to the previous screen without saving the changes, choose the Back item.
6. Press the Options key. The options for setting the line or lines on which the probe pulse
will occur appears on the generator's display:
*OneLine
AllActive
AllLines
7. Press the soft key adjacent to the desired option, as follows:
• OneLine: Probe pulse occurs once per frame.
• AllActive: Probe pulse occurs on every active line in the frame.
• AllLines: Probe pulse occurs on every line in the frame.
Exp
1
10
100
Back
No
Exit
Visible-
