292 Chapter 9 Testing HDMI Sink Devices
2. If you have auto configured the formats through the EDID you may have to disable this
feature as follows:
a. Press the Sink key. The following information appears on the 882's display.
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
b. Press the Options key. The following information appears on the 882's display.
-EDID Formats
+HP Bypass
-Emulate
c. Choose not to EDID Formats by pressing the adjacent soft key. A - appears next
to EDID Formats, indicating it is disabled.
3. Press the Source key and select the first test format.
Note: Gaming formats on the 882 have the characters "4x" in their names (such as
"480i4x29" or "576i4x25"). For a listing of all HDMI formats, see the table on page 256.
If you have auto configured the formats through the EDID you may have to disable this
feature.
Alternatively, to select the format through the command line interface, enter the
following commands:
FMTP /tffs0/Library/Formats // Set format path to 882 memory
FMTL 480i4x29
FMTU
CDF
// Loads the 480i4x29 format
// Activates the 480i4x29 format
