882 Video Test Instrument User Guide (Rev A.35)
C
Colorimetry (see EIA/CEA-861-B standard, Table 9 for settings)
C1 C0 Colorimetry
0 0
0 1 SMPTE 170M ITU601
1 0
1 1
SC
Non-uniform Picture Scaling (see EIA/CEA-861-B standard, Table 11 for settings)
SC1 SC0 Non-Uniform Picture Scaling
0 0
0 1
1 0
1 1 Picture has been scaled horizontally and vertically
ETB
Line number of end of top bar representing the last line of a horizontal letterbox bar
area at the top of the picture (0 = no horizontal bar present at top of picture).
SBB
Line number of start of bottom bar representing the first line of a horizontal letterbox
bar area at the bottom of the picture.
ELB
Pixel number of end of left bar representing the last horizontal pixel of a vertical
pillar-bar area at the left side of the picture (0 = no vertical bar present at left of
picture).
SRB
Pixel number of start of right bar representing the first horizontal pixel of a vertical
pillar-bar area at the left side of the picture.
VIC
Video Format Identification Codes (see
PR
Pixel repetition for "2x" and "4x" formats (see EIA/CEA-861-B standard, Table 14 for
settings) This field is set automatically based on settings for
PR3 PR2 PR1
0 0 0
0 0 0
0 0 1
0 0 1
0 1 0
0 1 0
0 1 1
No data
ITU709
Future
No known non-uniform scaling
Picture has been scaled horizontally
Picture has been scaled vertically
DVIC
PR0 Pixel Repetition for Optional (2880)
0 No Repetition (i.e. pixel sent once)
1 Pixel sent 2 times (i.e. repeated
once)
0 Pixel sent 3 times
1 Pixel sent 4 times
0 Pixel sent 5 times
1 Pixel sent 6 times
0 Pixel sent 7 times
for settings).
NCPP and NPPP.
