882 Video Test Instrument User Guide (Rev A.35)
To enable DHCP for auto IP address configuration of the 882:
1. Press the Tools key. The Tools menu appears on the 882's display as shown below.
System
Sequence
Probe
AFC
2. Choose the System item by pressing the adjacent soft key. The System menu appears
on the 882's display as shown below.
*Clock
CalFactor
Network
Serial
3. Choose the Network item by pressing the adjacent soft key. The 882's IP address and
subnet mask appear on the 882's display as shown below.
IP Address
192.168.254.1
Subnet Mask
255.255.255.000
4. Press the Settings key. The Network Connection screen appears on the 882's display
as shown below.
Network Connection
Set TCP/IP
IP Address
206.135.215.168
If the DHCP configuration option is not visible, press the soft key adjacent to the arrow
symbol by SubnetMask or IP Address until the DHCP configuration screen appears.
Network Connection
TCP/IP
DHCP Enabled
NO
5. Change the setting to YES by pressing the + key.
Network Connection
TCP/IP
DHCP Enabled
YES
Reports
ImgShift
Analyzer
CEC
Clone
Server
About
Gpib
