32 Chapter 11 Testing EDID for HDMI
Example
S V D 0 1 Y
Short VIC
Video
Component
Descriptor
color
sampling
• SVD – Short Video Descriptor
• 01 – EIA/CEA-861-C Format Video Identification Code (for example, 01, 02, 06,
etc., listed on page 149)
• Y2 – Y indicates color difference. 2 = 4:2:2 pixel sample encoding. 4 = 4:4:4.
• 1 – Represents DMT0659 format, which is the first format (index 1) listed under
video identification code 01 in the table on page 256.
For pixel rate testing, the format naming nomenclature used is shown below:
S V D 0 1 H
Short VIC
Video
Frequency
Descriptor
(High / Low)
• SVD – Short Video Descriptor
• 01 – EIA/CEA-861-C Format Video Identification Code (for example, 01, 02, 06,
etc,. listed on page 256)
• H – Indicates the format is using the maximum (H = High) frequency required by
the compliance test; L indicates the format is using the minimum (L = Low)
frequency required by the compliance test.
• 01 – Represents the index of the format as listed under video identification code on
page 256.
To verify proper pixel encoding and pixel rate support:
1. Connect the 882 to the display under test.
2. Press the Sink key. The following information appears on the 882's display.
Manufacturer:SNY
Product Code:144
Serial#:7011007
Week:20 Year:1998
