882 Video Test Instrument User Guide (Rev A.35)
test and set the CDF is that it enables you to automatically generate a baseline CDF from
the sink devices EDID. The following table describes the EDID CDF parameters and their
settings.
Parameter
HDMI Output Count
HDMI Input Port
CEC Root Device
Primary AR: 4:3
HDTV
YUV on Other
60Hz
50Hz
640x480p/60
720x480p/60 4:3
720x480p/60 16:9
1280x720p/60 16:9
1920x1080i/60 16:9
1440x480i/60 4:3
1440x480i/60 16:9
Explanation
The number of outputs the sink under test has. It is a
value in the range of 0-9.
The CEC input on the sink under test. It is a value in the
range of 1-15.
Indicates if the CEC device is a root device (i.e. a TV
without a repeater). The values are + for yes and - for
no.
Indicates the primary aspect ratio of the sink device
under test. This can be either 4:3, 16:9 or both. The val-
ues are + for yes and - for no.
Indicates if the sink under test supports HDTV. The val-
ues are + for yes and - for no. The values are + for yes
and - for no.
Indicates if the sink under test supports YUV. The val-
ues are + for yes and - for no. The values are + for yes
and - for no.
Indicates whether the device supports formats with
60Hz frame rate. The values are + for yes and - for no.
Indicates whether the sink under test supports formats
with 50Hz frame rate. The values are + for yes and - for
no.
Indicates whether the sink supports the DMT0660 for-
mat. The values are + for yes and - for no.
Indicates whether the sink supports the 480p60 format
with a 4:3 aspect ratio. The values are + for yes and - for
no.
Indicates whether the sink supports the 480p60SH for-
mat with a 16:9 aspect ratio. The values are + for yes
and - for no.
Indicates whether the sink under test supports the
720p60 format. The values are + for yes and - for no.
Indicates whether the sink under test supports the
1080i60 format. The values are + for yes and - for no.
Indicates whether the sink under test supports the
480i2x60 format with double clocking at 4:3 aspect ratio.
The values are + for yes and - for no.
Indicates whether the sink under test supports the
480i2x60 format with double clocking at 16:9 aspect
ratio. The values are + for yes and - for no.
