202
Appendix A Command Reference
Command
Type
FSPP
Digital Sync Polarity Set digital frame sync pulse polarity
PSPP
Digital Sync Polarity Set probe pulse polarity
LSPP
Digital Sync Polarity Set digital line sync pulse polarity
HSPG
Digital Sync Gates
VSPG
Digital Sync Gates
CSPG
Digital Sync Gates
PSPG
Digital Sync Gates
LSPG
Digital Sync Gates
FSPG
Digital Sync Gates
PCPG
Digital Sync Gates
Description
Enable/disable digital horizontal sync output
Enable/disable digital vertical sync output
Enable/disable all digital composite sync outputs
Enable/disable probe pulse on special sync
output
Enable/disable digital horizontal sync output
Enable/disable digital frame sync output
Enable/disable pixel clock pulse
