136 Chapter 13 Testing HDCP on HDMI
2. Activate the HDMI-H interface on the output port as follows:
a. Press the Interface key. A listing of signal interfaces appears on the 882's display
as shown below.
VGA
*
HDMI-D
HDMI-H
b. Choose the HDMI-H item by pressing the adjacent soft key. The interface is
activated and the display is shown below.
VGA
HDMI-D
*HDMI-H
Alternatively, to activate the interface through the command line interface, enter the
following commands:
XVSI 4 // Activates the HDMI-H interface
ALLU // Applies the interface setting to the 882
3. Press the Interface key repeatedly until the following menu appears:
HDMI IN 1
*
HDMI IN 2
4. Choose the HDMI IN 1 by pressing the adjacent soft key.
5. Verify that the repeater is sending in video using the Timing measurement function of
the analzyer. Refer to
on running the timing test.
Verify that the source is outputting one of the following formats: 1) 640x480p at
59.94/60Hz; 2) 720x480p at 59.94/60Hz; 3) 720x576p at 50Hz.
Verify that the source is outputing the RGB color space:
If the 882 cannot detect the incoming video, enter the following command to turn on the
EST:
QD:PROD:EST
6. Press the Tools key and choose the Reports item by pressing the adjacent soft key.
The following is displayed on the 882's LCD.
EDID
Misc
CVBS
S-VIDEO
SDI
CVBS
S-VIDEO
SDI
"Measuring timing of video
// Turns on the EST
Packets
HDCP
signal" on page 260 for information
