List of Tests

118 Chapter 13 Testing HDCP on HDMI
The features provided by the EST are specifically used for the following tests:
Index Test
1 1A_01 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
11 1B_01 (Transmitter Downstream
w/Repeater)
20 2C_04 (Receiver Upstream
w/Transmitter) (w/DVI
Transmitter)
21 3A_01 (Repeater Downstream
w/Receiver) (Between HDMI
Capable Transmitter and HDMI
Capable Receiver)
26 3B_01 (Repeater Downstream
w/Repeater)
The following table describes the HDCP compliance tests performed with the 882EA.
Index Test
1 1A_01 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
2 1A_02 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
3 1A_03 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
4 1A_04 (Transmitter Downstream
w/Receiver) w/HDMI Capable
Receiver
EST Function
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
Positions the encryption enable pulse in the
vsync or vertical blanking at three different loca-
tions (beginning, center and end).
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
Verifies that the encryption enable/disable pulse
is transmitted during the valid period, that no data
islands, video data or guard band is transmitted
during the keep-out period and that no data island
is transmitted during Line Key Calc period on the
encrypted frame.
Description
Regular Procedure: With HDMI Capable
Receiver
Regular Procedure: HDCP_HPD After Writing
Aksv
Regular Procedure: HDCP_HPD After Starting
Third Part of Authentication
Irregular Procedure: (First Part of Authentication)
HDPC Port Access
