882 Video Test Instrument User Guide (Rev A.35)
Tab Description / Function
Digital Audio Selecting the General tab opens up an application screen that enables you
to define the digital audio parameters for a custom format or modify these
parameters of an existing format. (See
page 180 below for details on each of the parameters.)
AFD Selecting the General tab opens up an application screen that enables you
to define the AFD parameters for a custom format or modify these
parameters of an existing format. (See
183 below for details on each of the parameters.)
The table below describes the Problem List status panels for the New Format window.
Entity Type
Unit Pull-down menu
Interface Pull-down menu
Instrument Status text field
(Connection Status)
Error log
Description / Function
Enables you to select the type of 882 unit that you are
viewing problems for. Options are:
• C/CA - 882C or 882CA
• D - 882D
• E - 882E
• EA/DP - 882E (HDMI), 882EA (HDMI), 882E
(DisplayPort)
•
Enables you to select the type of interface you are
defining a format for. Options are:
• Analog - Component analog (RGB or YPbPr)
• CVBS - Composite Video Baseband Signal
• S-Video - Y/C
• DVI - DVI from the DVI output
• HDMI-D - DVI from the HDMI output
• HDMI-H - HDMI
• SDI - SDI and HDSDI
Shows the current connection status.
Red Dot Indicates that an error has occurred. In the future
warnings will be supported which will be yellow.
# (Number) An integer assigned to the error in the log list. This is a
number assigned in sequence as the errors occur.
Error # The 882 error number for a particular error type. The
error list can be found in
Description A text description of the error.
"New Format - Digital Audio
"New Format - AFD Tab" on page
"Error code descriptions".
Tab" on
165
