VLT Micro Drive FC 51 Design Guide
VLT Micro Drive FC 51 Quick Guide
VLT Micro Drive FC 51 Programming Guide
FC 51 LCP Mounting Instruction
FC 51 De-coupling Plate Mounting Instruction
FC 51 Remote Mounting Kit Mounting Instruction
FC 51 DIN Rail Kit Mounting Instruction
FC 51 IP21 Kit Mounting Instruction
FC 51 Nema1 Kit Mounting Instruction
X = Revision Number, Y = Language code

1.1.3 Symbols

Symbols used in this guide.
NOTE
Indicates something to be noted by the reader.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or
equipment damage.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
*
Indicates default setting
6
VLT Micro Drive Design Guide
Title Literature
MG.02.K1.YY
MG.02.BX.YY
MG.02.CX.YY
MI.02.AX.YY
MI.02.BX.YY
MI.02.CX.YY
MI.02.DX.YY
MI.02.EX.YY
MI.02.FX.YY
MG02K102 - VLT

1.1.4 Abbreviations

no.
Alternating current
American wire gauge
Ampere/AMP
Automatic Motor Tuning
Current limit
Degrees Celsius
Direct current
Electro Magnetic Compatibility
Electronic Thermal Relay
Frequency Converter
Gram
Hertz
Kilohertz
Local Control Panel
Meter
Millihenry Inductance
Milliampere
Millisecond
Minute
Motion Control Tool
Nanofarad
Newton Meters
Nominal motor current
Nominal motor frequency
Nominal motor power
Nominal motor voltage
Protective Extra Low Voltage
Printed Circuit Board
Rated Inverter Output Current
Revolutions Per Minute
Regenerative terminals
Second
Synchronous Motor Speed
Torque limit
Volts
The maximum output current
The rated output current supplied by the
frequency converter
®
is a registered Danfoss trademark
AC
AWG
A
AMT
I
LIM
°C
DC
EMC
ETR
FC
g
Hz
kHz
LCP
m
mH
mA
ms
min
MCT
nF
Nm
I
M,N
f
M,N
P
M,N
U
M,N
PELV
PCB
I
INV
RPM
Regen
sec.
n
s
T
LIM
V
I
VLT,MAX
I
VLT,N
