Mitsubishi GOT1000 GT15 User Manual page 92

No. Name
1) POWER LED
2) Display screen
3) Touch key
4) USB interface
5) RS-232 interface
6) Power terminal
7) Extension interface
8) CF card interface
9) CF card access LED
10) CF card access switch
Optional function board
11)
interface
Multi-color display board
12)
*1
interface
13) Reset switch
14) Hole for unit installation fitting Hole for inserting the unit installation fitting
15) Battery holder
*1
Remark
4
4.4 Part Names and Settings of the GT156
- 10
Lit in green
Lit in orange
Blinks in orange/green : Blown back light bulb
Not lit
Displays the utility and the user creation screen.
For operating the touch switches in the utility and the user creation screen
For connecting a personal computer
(Connector type: TYPE Mini-B)
For communicating with a controller or connecting a personal computer
(Connector type: D sub 9-pin)
Power input terminal, LG terminal, FG terminal
For installing an extension unit
For installing a CF card
Lit : CF card accessed
Not lit : CF card not accessed
Used for stopping the access to the CF card before removing the CF card from the
GOT
ON : CF card being accessed (CF card removal prohibited)
OFF : CF card not accessed (CF card removal possible)
For installing the optional function board
For installing the multi-color display board (For GT1562-VN, 65536 color display is
not supported even with the multi-color display board installed.)
Hardware reset switch
(Inoperative in the bus connection or with the bus connection unit installed)
Houses the battery.
For the multi-color display board, refer to the following.
3.2.4 GT1565-V, GT1562-VN
Connector used for the RS-232 interface
The specification of the connector used for the RS-232 interface of GT156
follows.
Manufacturer :DDK Ltd.
Mode name
: Power is correctly supplied
: Screen saving
: Power is not supplied
:17LE-23090-27 (D4CK) or equivalent product
Description
is as
