8.1 Communication Unit
The communication unit is used to relate the GOT extension interfaces to the system at the connection
destination.
To connect the communication unit, make Communication Settings for communications with a PLC.
For details of connection, refer to the following manual.
•GOT1000 Series Connection Manual for GT Works3 and a controller used
•GOT1000 Series Connection Manual for GT Designer2/GT Works2
8.1.1
Applicable communication unit
The following communication units are applicable for GT15.
Product name
GT15-QBUS
GT15-QBUS2
GT15-ABUS
GT15-ABUS2
Bus connection unit
GT15-75QBUSL
GT15-75QBUS2L
GT15-75ABUSL
GT15-75ABUS2L
GT15-RS2-9P
Serial communication
GT15-RS4-9S
unit
GT15-RS4-TE
Ethernet
GT15-J71E71-100
communication unit
GT15-J71LP23-25
MELSECNET/H
communication unit
GT15-J71BR13
Model
*1
For QCPU (Q mode)/motion
controller CPU (Q series)
connection (standard model)
*1
*1
For A/QnACPU/motion
controller CPU (A series)
connection (standard model)
*1
For QCPU (Q mode)/motion
controller CPU (Q series)
connection (slim model)
For A/QnACPU/motion
controller CPU (A series)
connection (slim model)
*1
For RS-232 interface connection, connector type
*1
For RS-422 interface connection, connector type
*1
For RS-422 interface connection, terminal block type
Ethernet (100Base-TX/10Base-T) unit
*2
Optical double loop unit
*2
Coaxial bus unit
Description
For last GOT,
Number of IN side connectors: 1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
For last GOT,
Number of IN side connectors: 1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
For last GOT,
Number of IN side connectors: 1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
For last GOT,
Number of IN side connectors: 1
For intermediary and last GOT,
Number of IN and OUT side
connectors: 1 for each side
8.1 Communication Unit
8.1.1 Applicable communication unit
1
2
3
4
5
6
For 15",
12.1",
10.4",
8.4",
5.7"
7
8
8
