(4) Channel number specification menu BOX
Set channel No. to use with standard interface or extend interface.
Refer to this section (5) for driver that can be assigned to each channel.
0
1 to 4
*1
5 to 7
*1
8
9
*
• Fixed to 9 for the USB interface.
*1 The same device cannot be used for ChNo.5 to ChNo.8 simultaneously.
For restrictions on external devices, refer to the following manual.
(5) Driver display BOX
The name of communication driver assigned to the channels or the driver set with the
Communication Setting of GT Designer3 or GT Designer2 is displayed.
For details of drivers to be displayed, refer to the following manual.
Display [None] in the driver display BOX in case of the followings.
• The communication driver is not installed. (
• In channel number specification menu BOX, [0] is set.
• The communication unit type and the communication driver are mutually not corresponding at
the extend interface side.
When the channel number for the standard I/F-1 is set to [9], the communication driver [Host (PC)]
or [Host (Modem)] can be selected.
When the channel number for the standard I/F-2 is set to [9], the communication driver [Host (PC)]
is automatically assigned.
For how to set the communication driver, refer to the following.
10.1.4
10
10.1 Communication Setting
- 4
10.1.3 Communication setting contents
: Set when the communication interface is not used.
: Set when connecting to a controller.
(Except bar code reader and RFID controller)
: Set when connecting to a barcode reader, an RFID controller or a PC.
Only extend I/F setting is possible.
: Set when connecting to a fingerprint unit, a barcode reader, an RFID controller or a
PC.
Only standard I/F setting is possible.
: Set when connecting with PC (GT Designer3 or GT Designer2). (For USB and RS-
232 interface, the simultaneous setting is possible. However, when either interface
is during communication, communication is not possible for another interface.)
: Set "*" when using the gateway function (when connection types except the
Ethernet connection is used for connecting to controllers), Ethernet download
function, printer, video display, RGB display, RGB output, CF card unit, CF card
extension unit, sound output, or external I/O.
•GOT1000 Series Connection Manual for GT Works3 and a controller used
(1.1 Setting the Communication Interface)
•GT Designer2 Version
(3.7 Communication Interface Setting (Communication Settings))
•GOT1000 Series Connection Manual for GT Works3 and a controller used
(1.1 Setting the Communication Interface)
•GT Designer2 Version
(3.7 Communication Interface Setting (Communication Settings))
Setting of Host (PC)/Host (Modem)
Screen Design Manual
Screen Design Manual
13.2 OS Information)
