14. GOT SELF CHECK (DEBUG & SELF CHECK)
The GOT can display the screen for debugging or self-checking.
The following describes the functions available as the debugging and self checking function.
Item

Debug

Self check
System alarm display
GOT start time
Operator info.
Management
Fingerprint
authentication
14.1 Debug
In this manual, the overview of the debuggingfunction and the operation procedure until displaying the
screen are described.
For display contents and operation procedure of debuggings, refer to the following manual.
• GOT1000 Series User's Manual (Extended Functions, Option Functions)
• GOT1000 Series Extended/Option Functions Manual for GT Designer2/GT Works2

14.1.1 The Debug function

The Debug function is designed to confirm the device status of PLC CPU and to make the response for PLC
system trouble more efficient.
The following shows the functions that can be performed with the Debug function.
Item
System monitor
Ladder monitor
A list editor
FX list editor
Intelligent unit monitor
System monitor, Ladder monitor, A list editor, List editor for MELSEC-A,
intelligent module monitor, Network monitor, Q motion monitor, servo
amplifier monitor, CNC monitor, Backup/restoration, and CNC data I/O,
SFC monitor, Ladder editor, Motion SFC monitor
Memory check, Drawing check, Font check, Touch panel check, I/O check,
NETWK unit status display
GOT errors, CPU errors, network errors
Time when the GOT was started
Operator management, Password change, Function setting
Administrator password setting, Contents registered list
for GT Works3
The device of PLC CPU and buffer memory of intelligent function
module can be monitored or tested.
The program of PLC CPU can be monitored in ladder format.
The sequence program of ACPU can be list edited.
The sequence program of FXCPU can be list edited.
Buffer memory in the intelligent function module can be monitored
or the data can be changed on the dedicated screen.
And the signal status of I/O modules can be monitored.
Description
Description
14.1.1 The Debug function
Reference page
14-1
14-4
14-35
14-37
14-39
14-58
Compatible
Compatible
GT
GT Works3
Designer2
14
14.1 Debug
- 1
