STARTUP MODE:
Run Application
NETWORK INTERFACE PARAMETERS:
TMS is present
Use Message Exchange to download image
LAN IP address will be obtained from etc/bootptab file
HARDWARE PARAMETERS:
Serial channels will use a baud rate of 9600
This board's Ethernet hardware address is 00:80:01:A0:02:47
This board's clock frequency is 40 MHz
This board has 16 Megabytes of DRAM
SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is DISABLED and will NOT timeout.
MXD BOOT LOADER PARAMETERS :
The download file will come from the TMS
STARTUP DELAY:
Will wait 5 seconds before start up to allow parameter modifications
--------------------------------------------------------------
(M)odify any of this or (C)ontinue? [M] c
Writing the modified parameters to the removable EEprom

Testing the DCC and TPM Configuration

1. Restart SRP and reset the TMS.
2. Monitor the DCC console port, and check that the following message appears.
DCC-3000 Rom $Revision: 1.8 $, Checksum = 0x192740c9
dcc3k_rom.elf,
Copyright (C) 2013, Avaya Inc. All rights reserved
--------------------------------------------------------------------------
START-UP MODE:
Run the ROM Bootloader
HOST DEBUGGER CONNECTION (if activated):
Network connection
NETWORK INTERFACE PARAMETERS:
TMS is present
Use Message Exchange to download image
LAN IP address will be obtained from bootp.
HARDWARE PARAMETERS:
Serial channels will use a baud rate of 9600
Processor: MPC8260 (Mask 0x24), PPC_clk = 198MHz, CPM_clk = 165MHz
SDRAM : 64MB, cycle time 8.0ns @ Cas Latency=3
This board's Ethernet hardware address is 00:80:01:D0:08:B1
SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is DISABLED and will NOT timeout.
MXD BOOT LOADER PARAMETERS :
The download file will come from the TMS
STARTUP DELAY:
After board is reset, start-up code will wait 5 seconds
--------------------------------------------------------------------------
To change any of this, press Enter, Return, or space key within 5 seconds
MII:FCC1: Link is 100Mbps full duplex.
MII:FCC3: Timeout waiting for Autonegotiate done.
Obtaining IP and filename from BOOTP
HostIp is 10.7.20.124
This board's IP is 10.7.20.34
