Nominal Input
Input Current per PDU
(Amps)
Number of Feeds
Passport 8600
Number of Feeds 8600
only
Total Feeds per Cabinet
Total Power
Note:
The DC Power Distribution Unit (DC PDU) is intended to provide redundant power. In case of one leg
failure, the total current (leg 1 + leg 2) must not exceed the single leg rating of 30 Amps. Total current
depends on equipment configuration.
Note:
The DC Power Distribution Unit (DC PDU) is intended to provide redundant power. In case of one leg
failure, the total current (leg 1 + leg 2) must not exceed the single leg rating of 200 Amps. Total current
depends on equipment configuration.
The current server is rated at .22 KVA maximum. The information in the table assumes 5 servers
per PDU, 24 servers and a Passport 8600. Systems containing fewer servers require less.
Heat dissipation for Speech Server, based on 751 BTU rating of servers, plus Passport.
Note:
Electrical service must be within 5 feet (1.5 m) of the equipment. Electrical service must be
dedicated (isolated), separately protected (fuse, circuit breaker), and properly grounded.

Environmental Characteristics MPS Cabinet

Temperature
Humidity
Altitude
October 2014
-48 Volts DC Terminal
Block)
60 Amps max
180 Amps Maximum See
Note:
5 pairs + 5 pair
redundant (10 max)
29 Amps (Maximum)
3 (Maximum)
13 (Maximum)
9660 Watts (Typical
Configuration) 11040
Watts (Maximum
Configuration)
Operating
50 to 104 F 10 to 40 C
4 to 80% Non-Condensing
0 to 8000 Feet 0 to 2439 Meters
Avaya Media Processing Server 1000 Hardware Installation and Maintenance
Comments? infodev@avaya.com
Environmental Characteristics MPS Cabinet
-48 Volts DC (PDU) -48 Volts DC Breaker
Panel
26 Amps (Typical) 30 4
Amps (Maximum)
400 Amps Maximum
See Note 2:
Not applicable
Not applicable
Non-Operating
-22 to 140 F - 30 to 60 C
8 to 80% Non-Condensing
0 to 40000 Feet 0 to 12190 Meters
