Figure 50: NIC Edge View
1. Connect a serial console to the remote terminal connector on the NIC. See
Connection
2. Press the reset button on the NIC. See preceding diagram and
page 147. The ROM banner and current settings are displayed on the serial console.
3. Press any key within 5 seconds to stop the NIC from booting.
4. Verify the items are set as follows in ROM.
NIC-2000 Rom Version V3.0, Checksum = 0x0434b441
NIC_rom.elf,
Copyright (C) 2000, Avaya Incorporated
-----------------------------------------------------
STARTUP MODE:
Run Application
NETWORK INTERFACE PARAMETERS:
LAN IP address will be obtained from etc/bootptab file
LAN interface's subnet mask is 0xffff0000
HARDWARE PARAMETERS:
Serial channels will use a baud rate of 9600
This board's Ethernet hardware address is 00:80:01:B0:00:1A
This board's clock frequency is 28 MHz, bus ratio is 1:1
October 2014
on page 158.
Release Developmental [02/11/00 02:00:10 PM]
Avaya Media Processing Server 1000 Hardware Installation and Maintenance
Comments? infodev@avaya.com
NIC Boot ROM
Debug Terminal
Resetting the NIC on
