MPS Specifications
Nominal Input
Note:
The DC Power Distribution Unit (DC PDU) is intended to provide redundant power. In case of one leg
failure, the total current (leg 1 + leg 2) cannot exceed the single leg rating of 100 Amps. Total current
depends on equipment configuration.

AC Electrical Specifications MPS Processor Cabinet

Nominal Input
Voltage Range
Plug Type
Cord Length
Input Current per PDU (Amps)
Number of Feeds
Passport 8600
Number of Feeds 8600 only
Total Feeds per Cabinet
Total Power
Heat Dissipation

DC Electrical Specifications MPS Processor Cabinet

Nominal Input
Voltage Range
Plug Type
Avaya Media Processing Server 1000 Hardware Installation and Maintenance
236
-48 Volts DC (Terminal
Block)
115 Volts AC Single Phase
100 – 135 AC
NEMA L5-20P plug 15 AMP Rated
Cord
14.7 Feet (4.5 meters)
12 Amps (Typical) 15 Amps
(Maximum) (Per Feed)
2 min (5 max)
12 Amps (Maximum)
3 (Maximum)
8 max
9660 Watts (Typical Configuration) 11040 Watts (Maximum Configuration)
20,000 BTU/Hour
Note:
Heat dissipation calculated by
specific configuration.
-48 Volts DC Terminal
Block)
-40 to -56 VDC
AMP #52043 or
equivalent
Comments? infodev@avaya.com
-48 Volts DC (PDU)
230 Volts AC Single Phase
190 – 265 AC
NEMA L6-20P 15 AMP Rated Cord
14.7 Feet (4.5 meters)
6 Amps (Typical) 15 Amps
(Maximum) (Per Feed)
2 min (5 max)
6 Amps (Maximum)
3 (Maximum)
8 max
0
-48 Volts DC (PDU)
-40 to -56 VDC
ETC Molex p/n
HDCL-6142-CC or
equivalent
-48 Volts DC Breaker
Panel
-48 Volts DC Breaker
Panel
40 to -60 VDC
Panduit (LCDX6-14A- L),
T&B (54205), FCI
(YAV4CL-2TC14-FX) or
equivalent
