SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is DISABLED and will NOT timeout.
MXD BOOT LOADER PARAMETERS :
The download file will come from the TMS
STARTUP DELAY:
After board is reset, start-up code will wait 5 seconds
--------------------------------------------------------------------------
To change any of this, press Enter, Return, or space key within 5 seconds
3. Set the Watchdog timer to DISABLED.
4. If all displayed values are correct, select the Continue option by typing c. To modify the
current settings:
a. Select the Modify option by typing m:
(M)odify any of this or (C)ontinue? [M] m
b. Press Enter to accept the current values as they are.
c. To change a value, type the new value after the prompt.
For each of the following questions, you can press <Return> to select the
value shown in braces, or you can enter a new value.
How should the board boot?
1. pROBE+ standalone mode
2. pROBE+ waiting for host debugger via serial connection
3. pROBE+ waiting for host debugger via a network connection
4. Run the Application
Which one do you want? [4]
NETWORK INTERFACE PARAMETERS:
Enter 0 if TMS absent
Enter 1 if TMS present and you'd like to TFTP the image
Enter 2 if TMS is present and you'd like to use the MXD to get the image
: [2]
Do you want a LAN interface?
BOOTP, RARP or FIXEDIP can obtain this Board's IP.
The default method is FIXED
Enter Y to change the default
The current LAN IP address is [192.168.101.5]
Use a subnet mask for the LAN interface?
Should there be a default gateway for packet routing?
HARDWARE PARAMETERS:
Baud rate for serial channels [9600]
Do you want to change the board's clock rate? [N]
Do you want to change the SWT status? [N]
Do you want to change the board's Ethernet address? [N]
ROM BOOTLOADER PARAMETERS:
STARTUP DELAY:
How long (in seconds) to delay before starting up? [5]
d. After all prompts are answered, the original verify screen appears again with the new
values. To make additional changes, select the Modify option again. To save the
changes, select Continue.
(M)odify any of this or (C)ontinue? [M] c
Writing the modified parameters to the removable EEprom
Waiting for FPGA startup Flag
...
