Configuration
This board has 32 Megabytes of DRAM
SOFTWARE WATCH DOG TIMER STATUS:
The watch dog timer is ENABLED and will timeout / RESET in 120 seconds.
TFTP BOOT LOADER PARAMETERS :
The IP and download file to start will come from the /etc/bootptab file
STARTUP DELAY:
Will wait 5 seconds before start up to allow parameter modifications
-----------------------------------------------------
(M)odify any of this or (C)ontinue? [C] c
a. IP address of NIC is set to /etc/bootptab.
b. Watchdog timer is ENABLED.
5. If all displayed values are correct, select the (C)ontinue option by typing c. To modify any
current settings:
a. Select (M)odify option by typing m:
(M)odify any of this or (C)ontinue? [M] m
b. Press Enter to accept the current values of items
For each of the following questions, you can press <Return> to select the
value shown in braces, or you can enter a new value.
How should the board boot?
1. pROBE+ standalone mode
2. pROBE+ waiting for host debugger via serial connection
3. pROBE+ waiting for host debugger via a network connection
4. Run the Application
Which one do you want? [4]
NETWORK INTERFACE PARAMETERS:
Do you want a LAN interface?
BOOTP, RARP or FIXEDIP can obtain this Board's IP.
The default method is BOOTP
Enter Y to change the default
Enter 0 for RARP, 1 for BOOTP, 2 for FIXED [1] 1
New configuration is:
Use a subnet mask for the LAN interface?
Should there be a default gateway for packet routing?
HARDWARE PARAMETERS:
Baud rate for serial channels [9600]
Do you want to change the board's clock rate? [N]
Do you want to change the SWT status? [N]
Do you want to change the board's Ethernet address? [N]
ROM BOOTLOADER PARAMETERS:
STARTUP DELAY:
How long (in seconds) to delay before starting up? [3]
c. To change a value, type the new value after the prompt. Repeat until all the values are
confirmed or changed.
6. When all prompts are finished, the original verify screen is displayed again with new values.
To make additional changes, select (M)odify option. To save the changes and boot, select
(C)ontinue. The NIC boots, and information, as in the following example, is displayed.
(M)odify any of this or (C)ontinue? [C]
Writing the modified parameters to the removable EEprom
Starting the TFTP download...
Avaya Media Processing Server 1000 Hardware Installation and Maintenance
146
//matches the program memory installed
[Y]
[N] y
BOOTP
Comments? infodev@avaya.com
[N]
[N]
