Avaya Communication Server 1000 Port Utilization – Issue 4.04
Avaya Port Matrix:
Communication Server 1000
Issue 4.04
23 Jun 2014
Avaya – Proprietary.
1
Use pursuant to the terms of your signed agreement or Avaya policy.
