1.1.0 (Jul 9 2003 - 11:03:10)
CPU Test Passed
LX-4016 (Copperhead) 16-port unit
The system is running on DC
Warning: DC_B bit is set in CPLD System Fail Status Register
No system failures were discovered
CPLD Test Passed
FEC Test Passed
...........................
...........................
Welcome to MRV Communications, In-Reach Product Division.
Port 0 Speed 9600
Update the Server Software
Run the update software command. The current version of the software can be displayed with the
show version command.
The default IP for MpsAp1 is 10.7.200.1. Substitute your IP, if different.
Login: InReach
Password: ****** (access)
InReach:0 >enable
Password:******(system)
InReach:0 >>update software 10.7.200.1
.......................................................
................................TFTP download complete,
copying Software image to flash
.......................................................
.......................................................
.......................................................
.......................................................
.......................................................
InReach:0 >>save config flash
.................
Creating a bootptab Entry
Edit the file /etc/bootptab on the selected bootp/TFTP server. Add the following entry for the
Terminal Server.
In-Reach:
:sm=255.255.0.0:gw=10.7.200.1:td=/tftpboot:ht=ethernet:
ha=XXXXXXXXXXXX:ip=10.7.200.50"
where XXXXXXXXXXXX is the MAC address without the colon separators. For Example:
In-Reach:
:sm=255.255.0.0:gw=10.7.200.1:td=/tftpboot:ht=ethernet:
ha=00a09c000207:ip=10.7.200.50.
Set the Terminal Server to Boot the Configuration from the TFTP host
1. Run the config command.
InReach:0 >>config
Config:0 >>boot config from net 10.7.200.1 lx000207
Config:0 >>exit
InReach:0 >>
2. Run the system status command to check that the Configuration Settings to Boot From is
set.
