Positioning the System for Servicing
These topics explain how to position the system so you can access the components
that need servicing.
"Extend the Server to the Maintenance Position" on page 72
■
"Release the CMA" on page 73
■
"Remove the Server From the Rack" on page 75
■
Related Information
"Safety Information" on page 62
■
▼ Extend the Server to the Maintenance Position
The following components can be serviced with the server in the maintenance
position:
Hard disk drives
■
Fan modules
■
Power supplies
■
DVD module
■
Fan boards
■
DIMMs
■
PCIe/XAUI cards
■
System battery
■
1. Verify that no cables will be damaged or will interfere when the server is
extended.
Although the cable management arm (CMA) that is supplied with the server is
hinged to accommodate extending the server, you should ensure that all cables
and cords are capable of extending.
2. From the front of the server, release the two slide release latches.
Squeeze the green slide release latches to release the slide rails.
72
SPARC T3-2 Server Service Manual • December 2013
