Install The Motherboard - Sun Oracle SPARC T3-2 Service Manual

11. Remove the service processor from the motherboard so you can reinstall it on
the new motherboard.
See "Remove the Service Processor" on page
Related Information
"Motherboard Overview" on page 164
■
"Install the Motherboard" on page 167
■
"Verify Motherboard Functionality" on page 173
■

▼ Install the Motherboard

1. Unpack the replacement motherboard and place it on an antistatic mat.
2. On the replacement motherboard, install the service processor that you removed
from the old motherboard.
See "Install the Service Processor" on page
3. Grasping the motherboard by the handle, place it into the chassis.
4. Hold the cables off to the side while grasping the handle on the motherboard
and sliding it toward the back of the chassis.
5. Reinsert and tighten the four bus bar screws that secure the motherboard to the
power supply backplane.
See "Install the Power Supply Backplane" on page
Note – Using a No. 2 screwdriver, tighten the bus bar screws until the power supply
backplane and the motherboard securely fasten to the bus bars.
6. Reinstall the System Remind button assembly (air divider) by sliding it into the
chassis.
Caution – After replacing the motherboard, inspect the dividing wall gasket, and
then install the plastic dividing wall securely. This dividing wall maintains a
pressurized seal between the server cooling zones. Without this pressurized seal, the
power supply fans will not be able to draw enough air to cool the drives properly.
7. Reinstall all memory risers.
See "Install a Memory Riser" on page
176.
179.
191.
121.
Servicing the Motherboard 167
