Increase Server Memory With Additional Dimms - Sun Oracle SPARC T3-2 Service Manual

"Verify DIMM Functionality" on page 130
■
"DIMM Configuration Error Messages" on page 132
■
▼ Increase Server Memory With
Additional DIMMs
This is a cold-service procedure that can be performed by customers.
1. Consider your first steps:
■
■
■
2. Unpack the new DIMMs and place them on an antistatic mat.
3. At a DIMM slot that is to be upgraded, open the ejector tabs and remove the
filler panel.
Do not dispose of the filler panel. You may want to reuse it if any DIMMs are
removed at another time.
4. Ensure that the ejector tabs on the connector that will receive the DIMM are in
the open position.
5. Align the DIMM notch with the key in the connector.
Caution – Ensure that the orientation is correct. The DIMM might be damaged if the
orientation is reversed.
126 SPARC T3-2 Server Service Manual • December 2013
Familiarize yourself with DIMM configuration rules.
See "DIMM Population Rules" on page
See "DIMM Rank Classification Labels" on page
Prepare the system for service.
See "Preparing for Service" on page
Remove the memory risers.
See "Remove a Memory Riser" on page
112.
115.
63.
120.
