▼ Install the Power Supply Backplane

1. Unpack the replacement power supply backplane and place it on an antistatic
mat.
2. Hold the power supply backplane at the end of the power supply cage and
connect the AC cables to the AC connectors on the power supply backplane.
Ensure that each AC cable is connected to the appropriate connector. The AC cable
on the right must be connected to the AC connector on the right and the AC cable
on the left must be connected to the AC connector on the left.
3. Insert the power supply backplane into position by completing the following
tasks.
a. Ensure that the tabs on the power board slide onto the hooks on the power
supply cage.
Servicing the Power Supply Backplane 191
