Identifying Server Components; Front Components - Sun Oracle SPARC T3-2 Service Manual

Identifying Server Components

These topics identify key components of the servers, including major boards and
internal system cables, as well as front and rear panel features.
"Front Components" on page 1
■
"Rear Components" on page 3
■
"Infrastructure Boards in the Server" on page 4
■
"Internal System Cables" on page 5
■
"Internal Components" on page 5
■
"Exploring Parts of the System" on page 7
■
Related Information
"Detecting and Managing Faults" on page 15
■
"Preparing for Service" on page 61
■

Front Components

The following figure shows the layout of the server front panel, including the power
and system locator buttons and the various status and fault LEDs.
Note – The front panel also provides access to internal hard drives, the removable
media drive (if equipped), and the two front USB ports.
