Sun SPARC Enterprise T5120 and

T5220 Servers

Administration Guide
Part No. 820-2179-14
October 2010, Revision A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPARC Enterprise T5120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Oracle SPARC Enterprise T5120

Summary of Contents for Sun Oracle SPARC Enterprise T5120

  • Page 1: T5220 Servers

    Sun SPARC Enterprise T5120 and T5220 Servers Administration Guide Part No. 820-2179-14 October 2010, Revision A...
  • Page 2 Copyright © 2009, 2010 Oracle and/or its affiliates. All rights reserved. FUJITSU LIMITED provided technical input and review on portions of this material. This software and related documentation are provided under a license agreement containing restrictions on use and disclosure and are protected by intellectual property laws.

  • Page 5: Table Of Contents

    Contents Using This Documentation ix Communicating With the System 1 ILOM Overview 1 ▼ Log In to ILOM 2 ▼ Log In to the System Console 3 ▼ Display the ok Prompt 3 ▼ Display the ILOM ->Prompt 4 ▼ Use a Local Graphics Monitor 5 Performing Common Tasks 7 ▼...
  • Page 6 Clear a Fault 49 Managing Logical Domains Software 51 Logical Domains Software Overview 51 Logical Domain Configurations 52 View OpenBoot Configuration Variables 53 OpenBoot Configuration Variables on the SCC 53 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 7 Index 57 Contents...
  • Page 8 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 9: Using This Documentation

    Using This Documentation This document includes general information about Oracle’s Sun SPARC Enterprise T5120 and T5220 servers as well as detailed instructions for configuring and administering the servers. This section contains the following topics: “UNIX Commands” on page ix ■...

  • Page 10: Related Documentation

    Getting Started SPARC Enterprise T5220 Server Getting Started Guide (DC) 820-5839 Printed Ships with system Planning SPARC Enterprise T5120 and T5220 Servers Site Planning Guide 820-2177 PDF Online HTML Installation SPARC Enterprise T5120 and T5220 Servers Installation Guide 820-2178 PDF...

  • Page 11: Documentation Feedback

    (http://www.sun.com/training) Documentation Feedback Submit comments about this document by clicking the Feedback[+] link at(http://docs.sun.com). Include the title and part number of your document with your feedback: SPARC Enterprise T5120 and T5220 Server Administration Guide, part number 820-2179-14. Using This Documentation...
  • Page 12 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 13: Communicating With The System

    Communicating With the System This section includes information on low-level communication with the system, using the Integrated Lights Out Manager (ILOM) tool andthe system console. This section contains the following topics: “ILOM Overview” on page 1 ■ “Log In to ILOM” on page 2 ■...

  • Page 14: Log In To Ilom

    Related Information “Log In to ILOM” on page 2 ■ Integrated Lights Out Manager (ILOM) Supplement for SPARC Enterprise T5120 and ■ T5140 Servers (http://docs.sun.com/app/docs/prod/int.lights.mgr) ▼ Log In to ILOM This procedure assumes the default configuration of the service processor as described in your server’s installation guide.

  • Page 15: Log In To The System Console

    “Log In to the System Console” on page 3 ■ ▼ Log In to the System Console “Log In to ILOM” on page 2. To access the system console from ILOM, type: -> start /SP/console Are you sure you want to start /SP/console (y/n) ? y Serial console started.

  • Page 16: Display The Ilom ->Prompt

    ▼ Display the ILOM ->Prompt ● Use one of the following ways to get to the ILOM -> prompt: From the system console, type the ILOM escape sequence (#.). ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 17: Use A Local Graphics Monitor

    4. Connect the USB keyboard cable to one USB port. 5. Connect the USB mouse cable to another USB port on the Sun SPARC Enterprise T5120 or T5220 server. “Display the ok Prompt” on page 3 Communicating With the System...
  • Page 18 You can now type system commands and view system messages using your local graphics monitor. Continue with your installation or diagnostic procedure, as needed. Related Information “Display the ok Prompt” on page ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 19: Performing Common Tasks

    Performing Common Tasks This section includes procedures for some common tasks performed on the servers: “Power On the System” on page 7 ■ “Power Off the System” on page 8 ■ “Reset the System” on page 9 ■ “Update the Firmware” on page 9 ■...

  • Page 20: Power Off The System

    Note – To perform an immediate shutdown, use the stop -force -script /SYS command. Ensure that all data is saved before entering this command. Related Information “Power On the System” on page 7 ■ “Reset the System” on page 9 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 21: Reset The System

    ▼ Reset the System It is not necessary to power the system off and on to perform a reset. ● To reset the system, from the Solaris prompt, type: # shutdown -g0 -i6 -y Related Information “Power Off the System” on page 8 ■...
  • Page 22 U-Boot 1.1.1 (May 23 2008 - 21:30:12) POST cpu PASSED POST ethernet PASSED Hit any key to stop autoboot: 0 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 23 ## Booting image at fe080000 IP Protocols: ICMP, UDP, TCP, IGMP Checking all file systems... fsck 1.37 (21-Mar-2005) Setting kernel variable ..done. Mounting local filesystems... Cleaning /tmp /var/run /var/lock. Identifying DOC Device Type(G3/G4/H3) ... Configuring network interfaces..Internet Systems Consortium DHCP Client V3.0.1 Copyright 2007 Internet Systems Consortium All rights reserved.
  • Page 24 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 25: Managing Disks

    RAID 0 (striping) and RAID 1 (mirroring) volumes using the Solaris OS raidctl utility. To configure and use RAID disk volumes on the Sun SPARC Enterprise T5120 and T5220 servers, you must install the appropriate patches. For the latest information about patches, see the product notes for your system.

  • Page 26: Creating Hardware Raid Volumes

    “Create a Hardware Mirrored Volume of the Default Boot Device” on page 19 ■ “Create a Hardware Striped Volume” on page 20 ■ “Configure a Hardware RAID Volume for the Solaris OS” on page 22 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 27: Create A Hardware Mirrored Volume

    Disk: 0.7.0 In this example, a single volume (c1t0d0) has been enabled. The Sun SPARC Enterprise T5120 or T5220 server’s on-board SAS controller can configure as many as two RAID volumes. Prior to volume creation, ensure that the member disks are available and that there are not two volumes already created.
  • Page 28 See the raidctl(1M) man page for additional details regarding volume and disk status. Note – The logical device names might appear differently on your system, depending on the number and type of add-on disk controllers installed. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 29 2. Type the following command: # raidctl -c primary secondary The creation of the RAID volume is interactive, by default. For example: # raidctl -c c1t0d0 c1t1d0 Creating RAID volume c1t0d0 will destroy all data on member disks, proceed (yes/no)? yes Volume c1t0d0 is created successfully! As an alternative, you can use the –f option to force the creation if you are sure of the member disks and sure that the data on both member disks can be lost.

  • Page 30: Delete A Hardware Raid Volume

    For more information about the raidctl utility, see the raidctl(1M) man page. Related Information “Disk Slot Numbers” on page 35 ■ “Delete a Hardware RAID Volume” on page 25 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 31: Create A Hardware Mirrored Volume Of The Default Boot Device

    ▼ Create a Hardware Mirrored Volume of the Default Boot Device Due to the volume initialization that occurs on the disk controller when a new volume is created, the volume must be configured and labeled using the format(1M) utility prior to use with the Solaris Operating System (see “Configure a Hardware RAID Volume for the Solaris OS”...

  • Page 32: Create A Hardware Striped Volume

    # raidctl Controller: 1 Disk: 0.0.0 Disk: 0.1.0 Disk: 0.2.0 Disk: 0.3.0 Disk: 0.4.0 Disk: 0.5.0 Disk: 0.6.0 Disk: 0.7.0 The preceding example indicates that no RAID volume exists. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 33 2. Type the following command: # raidctl -c –r 0 disk1 disk2 ... The creation of the RAID volume is interactive, by default. For example: # raidctl -c -r 0 c1t1d0 c1t2d0 c1t3d0 Creating RAID volume will destroy all data on spare space of member disks, proceed (yes/no)? yes May 16 16:33:30 wgs57-06 scsi: /pci@0/pci@0/pci@2/scsi@0 (mpt0): May 16 16:33:30 wgs57-06...

  • Page 34: Configure A Hardware Raid Volume For The Solaris Os

    ▼ Configure a Hardware RAID Volume for the Solaris OS After a creating a RAID volume using raidctl, use format(1M) to configure and label the volume before attempting to use it in the Solaris Operating System. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 35 1. Start the format utility: # format The format utility might generate messages about corruption of the current label on the volume, which you are going to change. You can safely ignore these messages. 2. Select the disk name that represents the RAID volume that you have configured. In this example, c1t2d0 is the logical name of the volume.
  • Page 36 <SUN146G cyl 14087 alt 2 hd 24 sec 848> selecting c1t2d0 [disk formatted] 4. Use the partition command to partition, or slice, the volume according to your desired configuration. See the format(1M) man page for additional details. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 37: Delete A Hardware Raid Volume

    5. Write the new label to the disk using the label command format> label Ready to label disk, continue? yes 6. Verify that the new label has been written by printing the disk list using the disk command. format> disk AVAILABLE DISK SELECTIONS: 0.
  • Page 38 In this example, the RAID volume is c1t0d0. Note – The logical device names might appear differently on your system, depending on the number and type of add-on disk controllers installed. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 39 3. To delete the volume, type the following command: # raidctl -d mirrored-volume For example: # raidctl -d c1t0d0 Deleting RAID volume c1t0d0 will destroy all data it contains, proceed (yes/no)? yes /pci@0/pci@0/pci@2/scsi@0 (mpt0): Volume 0 deleted. /pci@0/pci@0/pci@2/scsi@0 (mpt0): Physical disk 0 deleted. /pci@0/pci@0/pci@2/scsi@0 (mpt0): Physical disk 1 deleted.

  • Page 40: Hot-Plug A Mirrored Disk

    “Creating Hardware RAID Volumes” on page 14 ■ ▼ Hot-Plug a Mirrored Disk 1. Verify which hard drive corresponds with which logical device name and physical device name. “Disk Slot Numbers” on page SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 41 2. To confirm a failed disk, type the following command: # raidctl If the Disk Status is FAILED, then the drive can be removed and a new drive inserted. Upon insertion, the new disk should be GOOD and the volume should be SYNC.

  • Page 42: Hot-Plug A Nonmirrored Disk

    1. Verify which hard drive corresponds with which logical device name and physical device name. “Disk Slot Numbers” on page Ensure that no applications or processes are accessing the hard drive. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 43 2. Type the following command: # cfgadm –al For example: # cfgadm –al Ap_Id Type Receptacle Occupant Condition scsi-bus connected configured unknown c1::dsk/c1t0d0 disk connected configured unknown c1::dsk/c1t1d0 disk connected configured unknown c1::dsk/c1t2d0 disk connected configured unknown c1::dsk/c1t3d0 disk connected configured unknown c1::dsk/c1t4d0 disk...
  • Page 44 This warning is issued because these commands attempt to quiesce the (SAS) SCSI bus, but the server firmware prevents it. This warning message can be safely ignored in the Sun SPARC Enterprise T5120 or T5220 server, but the following step avoids this warning message altogether.
  • Page 45 4. Verify that the device has been removed from the device tree. Type the following command: # cfgadm -al Ap_Id Type Receptacle Occupant Condition scsi-bus connected configured unknown c1::dsk/c1t0d0 disk connected configured unknown c1::dsk/c1t1d0 disk connected configured unknown c1::dsk/c1t2d0 disk connected configured unknown...
  • Page 46 Note that c1t3d0 is now listed as configured. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 47: Disk Slot Numbers

    Related Information “Disk Slot Numbers” on page 35 ■ “Hot-Plug a Mirrored Disk” on page 28 ■ Disk Slot Numbers To perform a disk hot-plug procedure, you must know the physical or logical device name for the drive that you want to install or remove. If your system encounters a disk error, often you can find messages about failing or failed disks in the system console.
  • Page 48 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 49: Managing Devices

    Managing Devices This section contains information about managing devices in the servers, and the multipathing software supported: “Unconfigure a Device Manually” on page 37 ■ “Reconfigure a Device Manually” on page 38 ■ “Devices and Device Identifiers” on page 38 ■...

  • Page 50: Reconfigure A Device Manually

    /SYS/MB/GBEcontroller_number • GBE0 controls NET0 and NET1 • GBE1 controls NET2 and NET3 PCIe root complex /SYS/MB/PCIE USB ports (0-1, located on rear of /SYS/MB/USBnumber chassis) (0-3) /SYS/MB/CMP0/L2_BANKnumber /SYS/DVD SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 51: Sun Sparc Enterprise T5X20 Device Tree

    “Devices and Device Identifiers” on page 38 ■ Sun SPARC Enterprise T5x20 Device Tree The following table shows the correspondence of the Sun SPARC Enterprise T5120 and T5220 server devices to the Solaris Operating System device tree. Device (as Indicated on...

  • Page 52: Multipathing Software

    For the Sun SPARC Enterprise T5120 or T5220 servers, three different types of multipathing software are available: Solaris IP Network Multipathing software provides multipathing and ■...
  • Page 53 VERITAS Volume Manager (VVM) software includes a feature called Dynamic ■ Multipathing (DMP), which provides disk multipathing as well as disk load balancing to optimize I/O throughput. Sun StorageTek Traffic Manager is an architecture fully integrated within the ■ Solaris OS (beginning with the Solaris 8 release) that enables I/O devices to be accessed through multiple host controller interfaces from a single instance of the I/O device.
  • Page 54 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 55: Handling Faults

    Handling Faults The Sun SPARC Enterprise T5120 and T5220 servers provide many ways to find faults, including LEDs, ILOM and POST. For specific information about LEDs, and additional troubleshooting information, refer to the service manual for your server. This section contains the following topics: “Discovering Faults”...

  • Page 56: Discover Faults Using Ilom

    The virtual keyswitch can be used to run full POST diagnostics without having to modify the diagnostic property settings. Note that POST diagnostics can take a significant amount of time to run at system reset. “Log In to ILOM” on page 2 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 57: Locate The System

    2. At the ILOM -> prompt, type: -> set /SYS keyswitch_state=diag The system is set to run full POST diagnostics on system reset. 3. To return to your normal diagnostic settings after running POST, type: -> set /SYS keyswitch_state=normal Related Information “Discover Faults Using ILOM”...

  • Page 58: Bypassing Minor Faults

    For more information about ASR, refer to the service manual for your server. Related Information “Enable ASR” on page 47 ■ “Disable ASR” on page 47 ■ “View Information on Components Affected by ASR” on page 48 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 59: Enable Asr

    ▼ Enable ASR 1. At the -> prompt, type: -> set /HOST/diag mode=normal -> set /HOST/diag level=max -> set /HOST/diag trigger=power-on-reset 2. At the ok prompt, type: ok setenv auto-boot true ok setenv auto-boot-on-error? true Note – For more information about OpenBoot configuration variables, refer to the service manual for your server.

  • Page 60: View Information On Components Affected By Asr

    ■ “Enable ASR” on page 47 ■ “Disable ASR” on page 47 ■ “Unconfigure a Device Manually” on page 37 ■ “Reconfigure a Device Manually” on page 38 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 61: Clear A Fault

    ▼ Clear a Fault ● At the -> prompt, type: -> set /SYS/component clear_fault_action=true Setting clear_fault_action to true clears the fault at the component and all levels below it in the /SYS tree. Related Information “Discover Faults Using ILOM” on page 44 ■...
  • Page 62 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 63: Managing Logical Domains Software

    Managing Logical Domains Software Oracle’s Sun SPARC Enterprise servers support Oracle’s Logical Domains (LDoms) software that is used to create and manage logical domains. The software comprises LDoms-enabling code in the Solaris OS, LDoms-enabling code in System Firmware, and the Logical Domains Manager, which is the command-line interface. See your LDoms documentation for the latest information.

  • Page 64: Logical Domain Configurations

    ILOM set /HOST/bootmode config=configfile command to specify an LDoms boot configuration. For further information about /HOST/bootmode, see your server’s ILOM supplement. Related Information “Logical Domains Software Overview” on page 51 ■ SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...

  • Page 65: View Openboot Configuration Variables

    View OpenBoot Configuration Variables This section supplies information about variables storing configuration on the SCC: “OpenBoot Configuration Variables on the SCC” on page 53 ■ OpenBoot Configuration Variables on the SCC The following table describes the OpenBoot firmware configuration variables stored in non-volatile memory on the system.
  • Page 66 Firmware security password if security-password none security-mode is not none (never displayed). Do not set this directly. variable-name Number of incorrect security security-#badlogins none password attempts. SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 67 OpenBoot Configuration Variables Stored on the System Configuration Card (Continued) TABLE: Variable Possible Values Default Value Description If true, OpenBoot verbosity is set to diag-switch? true, false false maximum. If false, OpenBoot verbosity is set to minimum. Command to execute following a error-reset-recovery boot, sync, none boot...
  • Page 68 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
  • Page 69 Index Symbols devicee, unconfigure manually, 37 devices, managing, 37 -> commands set /SYS/LOCATE, 45 disk drives show /SYS/LOCATE, 45 LEDs Activity, 34 -> prompt OK-to-Remove, 32, 33 about, 1 logical device names, table, 35 -> prompt disk slot number, reference, 35 ways to access, 4 disk slot numbers, 35 disk volumes...
  • Page 70 4 OpenBoot configuration variables described, table, 53 system console input-device, 6 log in, 3 output-device, 6 system, communicating with, 1 OpenBoot variables, 53 output-device (OpenBoot configuration variable), 6 SPARC Enterprise T5120 and T5220 Server Administration Guide • October 2010...
