Motherboard Overview

When replacing the motherboard, remove the service processor and System
Configuration PROM from the old motherboard and install these components on the
new motherboard. The service processor contains the Oracle ILOM system
configuration data and the System Configuration PROM contains the system host ID
and MAC address. Transferring these components will preserve the system-specific
information stored on these modules.
System firmware consists of two components: a service processor component and a
host component. The service processor component is located on the service processor
and the host component is located on the motherboard. In order for the system to
operate correctly, these two components must be compatible.
After replacing the motherboard, the host firmware on the motherboard might be
incompatible with the service processor firmware on the service processor that you
transferred to the new motherboard. In this case, the system firmware must be
loaded as described in
Related Information
"Understanding Component Replacement Categories" on page 66
■
"Remove the Motherboard" on page 164
■
"Install the Motherboard" on page 167
■
"Verify Motherboard Functionality" on page 173
■

▼ Remove the Motherboard

Caution – Ensure that all power is removed from the server before removing or
installing the motherboard assembly. You must disconnect the power cables from the
system before performing these procedures.
Caution – These procedures require that you handle components that are sensitive
to static discharge. This sensitivity can cause the component to fail. To avoid damage,
ensure that you follow antistatic practices as described in
page
164 SPARC T3-2 Server Service Manual • December 2013
"Install the Motherboard" on page
63.
167.
"ESD Measures" on
