Sun Oracle SPARC T3-2 Service Manual page 25

Power Distribution/Fan Module Components
TABLE:
Item FRU
1 Power supply backplane
and cover
2 Air duct
3 Power supplies
4 Fan modules
5 Fan board unit
Related Information
"Understanding Component Replacement Categories" on page 66
■
"Servicing Power Supplies" on page 101
■
"Servicing Fan Modules" on page 93
■
"Servicing the Fan Board" on page 157
■
Notes
The power supplies must
be partially removed from
the chassis to remove this
component.
A plastic cover that rests
on top of the CPUs.
Two power supplies
provide N+1 redundancy.
All six fan modules must
be installed in the server.
A single fan board attached
to a fan board cage that
holds the fan modules.
Identifying Server Components
FRU Name (If Applicable)
N/A
N/A
/SYS/PS0
/SYS/PS1
/SYS/FANBD0/FAN0
/SYS/FANBD0/FAN1
/SYS/FANBD0/FAN2
/SYS/FANBD0/FAN3
/SYS/FANBD0/FAN4
/SYS/FANBD0/FAN5
/SYS/FANBD0
13
