Sun SPARC Enterprise T5120 Server
Getting Started Guide (For Models That Run on DC Input Power)
This guide describes the minimum steps you must perform to power on and boot Oracle's Sun SPARC
Enterprise T5120 server for the first time using the preinstalled Oracle Solaris™ Operating System (Solaris OS).
Servers that use DC input power require you to build and connect the power cords to specific safety
specifications. The specifications are described in the Sun SPARC Enterprise T5120 and T5220 Servers Installation
Guide that is available from
Sun SPARC Enterprise T5120 Server
FIGURE 1

Before You Begin

For quick installation and configuration, follow these steps. For more detailed information, refer to the complete
online product documentation set at:
Understand the following information before you set up the server for the first time:
Do not apply power until instructed to do so – This system includes a service processor (SP) that is used to
■
configure and boot the host server. To properly configure the host server and view SP messages, do not apply
power to the server until the SP and host networking connections are made, as described in this guide.
Choose the best instructions for your situation – The quick setup instructions in this guide work for any
■
networking environment, and require the use of a terminal device for connection to a serial port. If you have
a networking environment running DHCP, you can configure your system using the Ethernet management
port. To take advantage of the DHCP setup method, refer to the online installation guide in the online product
documentation set at:
http://docs.sun.com/app/docs/prod/sparc.t5120.
http://docs.sun.com/app/docs/prod/sparc.t5120
http://docs.sun.com/app/docs/prod/sparc.t5120
Shipping Contents
Quantity Item
1 Server
2 RJ-45 Ethernet cable
1 RJ-45 to DB-25 adapter (crossover)
1 RJ-45 to DB-9 adapter (crossover)
2 DC power connectors
1
