DIMM FRU Identifyers
TABLE:
DIMM FRU Identifyer (From Top to Bottom on Memory Riser)
/SYS/MB/CMPx/MRx/BOB1/CH1/D0
/SYS/MB/CMPx/MRx/BOB1/CH1/D1
/SYS/MB/CMPx/MRx/BOB1/CH0/D0
/SYS/MB/CMPx/MRx/BOB1/CH0/D1
/SYS/MB/CMPx/MRx/BOB0/CH0/D0
/SYS/MB/CMPx/MRx/BOB0/CH0/D1
/SYS/MB/CMPx/MRx/BOB0/CH1/D0
/SYS/MB/CMPx/MRx/BOB0/CH1/D1
Related Information
"Memory Riser Population Rules" on page 110
■
"Memory Riser FRU Names" on page 111
■
"DIMM Population Rules" on page 112
■
"Supported Memory Configurations" on page 113
■
"DIMM Rank Classification Labels" on page 115
■
"DIMM Configuration Error Messages" on page 132
■

DIMM Rank Classification Labels

All DIMMs installed in the server must have identical capacities. In addition, all
DIMMs associated with each CMP must have identical rank classifications.
Each DIMM includes a printed label identifying its rank classification (examples
below). Use these rank classification labels to identify the architecture of the DIMMs
installed in the server, as well as any replacment or upgrade DIMMs you intend to
install.
Servicing Memory Risers and DIMMs 115
