Diagnostic Flowchart Reference Table
TABLE:
Diagnostic Action Possible Outcome
Check Power OK The Power OK LED is located on the front and rear of
and AC Present the chassis.
LEDs on the server.
The AC Present LED is located on the rear of the server
(Flowchart item 1) on each power supply.
If these LEDs are not on, check the power source and
power connections to the server.
Run the ILOM show The show faulty command displays the following
faulty command kinds of faults:
to check for faults.
• Environmental faults
Flowchart item 2)
• Solaris Predictive Self-Healing (PSH) detected faults
• POST detected faults
Faulty FRUs are identified in fault messages using the
FRU name.
Check the Solaris The Oracle Solaris message buffer and log files record
log files for fault system events, and provide information about faults.
information.
• If system messages indicate a faulty device, replace
(Flowchart item 3)
• For more diagnostic information, review the SunVTS
Run SunVTS SunVTS is an application you can run to exercise and
software. diagnose FRUs. To run SunVTS, the server must be
running the Solaris OS.
(Flowchart item 4)
• If SunVTS reports a faulty device, replace the FRU.
• If SunVTS does not report a faulty device, run POST.
Run POST. POST performs basic tests of the server components and
reports faulty FRUs.
(Flowchart item 5)
Determine if the All Oracle ILOM-detected fault messages begin with the
fault was detected characters "SPT".
by the ILOM fault
For additional information on the reported fault,
management
including possible corrective action, go to this web site:
software.
(Flowchart item 6)
Where message-ID is the message ID contained in the
fault message. show faulty command.
18 SPARC T3-2 Server Service Manual • December 2013
the FRU.
report. (Flowchart item 4)
(Flowchart item 5)
Additional Information
• "Front Components" on
page 1
• TABLE: Service-Related
ILOM Commands on
page 35
• "Check for Faults Using the
show faulty Command" on
page 28
• "Interpreting Log Files and
System Messages" on
page 37
• "SunVTS Overview" on
page 58
• "Running POST" on page 45
• TABLE: ILOM Properties
Used to Manage POST
Operations on page 46
• "Display FRU Information
With the show Command"
on page 27
