8D–38 WIRING SYSTEM
Grounding Point
Reference Table
Connector No. Cable harness
B–6
Body harness
B–8
Engine room
C–16
harness
Engine room
C–36
harness
E–28
Engine ECGI
harness harness
E–30
Instrument har-
I–43
Location
Body–Center
Fender–LH
Fender–RH
Common
chamber chamber
Body-FRT
ness
Parts (Load)
Vanity mirror illumination, RR turn signal light - RH, Sun
roof control unit, Sun roof motor, Spot light, Taillight - RH,
Stoplight - RH
Vanity mirror illumination, Rear defogger relay, Rear
defogger SW, FRT door lock & power window SW – RH,
Cruise control unit, Digital clock, Cigarette lighter, Mirror
defogger – RH, Blower motor, Blower resistor, Electronic
thermostat, A/T shift lock, Flasher unit, Audio
Door lock actuator, FRT power window & door lock
SW – LH, RR wiper intermittent relay, Mirror defogger –
LH, Seat belt SW, Stoplight – LH
Anti – theft controller, Heater & A/C relay, Tail relay,
PCM, Headlight, High beam indicator light, Lighting relay,
Fog light relay, Illumination controller, Flasher unit,
Cornering relay, Power window relay, Headlight wiper
motor, Turn signal indicator light, Luggage room light,
Map light, Alarm & relay control unit
Fuel pump, RR door lock & power window SW, Shift lock
controller, Power door mirror motor, Mirror defogger SW,
Seat belt warning light
Fuel tank unit, Fuel warning light.
FRT combination light – LH, FRT turn signal light – LH,
Cornering light – LH, Vehicle speed snsor
Windshield washer motor (FRT)
Brake warning light, PCM
Data link connector
FRT combination light – RH, Cornering light – RH, FRT
turn signal light – RH
Fog light, EHCU
Kick down SW
Oxygen sensor, FRT-LH, FRT-RH, RR-LH, RR-RH, 4WD
indicator light, VSV; FRT axle
Windshield wiper motor
Engine hood SW
Windshield washer motor, Windshield washer motor
Ignition coil, Coil driver, EGR valve, I.A.T.S., T.P.S.
PCM, ECM main relay, Fuel pump relay, Cam position
sensor
Crank position sensor, Knock sensor, PCM, Mass air flow
sensor, Data link connector
SDM
