Main Data and Specifications

General Specifications
Engine
Type
Size
Pressure plate
Outside diameter
Clamping force
Spring finger height
Driven plate
Outside diameter inside diameter
Thickness
Clutch disengaged
Clutch engaged
Total friction area
Clutch control type
Clutch pedal free play
Clutch pedal stroke
Clutch pedal height
Torque Specifications
X22SE, TREMEC T5R
X22SE
Dry single plate type with diaphragm spring
240 mm (9.45 in)
299 mm (11.77 in)
5488 N (1235 lb)
37.5 – 39.5 mm (1.476 – 1.555 in)
240 160 mm (9.45 6.30 in)
8.3 mm (0.327 in)
8.0 mm (0.315 in)
251 2 cm@ (39 2 in@)
5 – 15 mm (0.20 – 0.59 in)
165.5 –175.5 mm (6.52 – 6.91 in)
178 – 188 mm (7.01 – 7.40 in)
CLUTCH
6VD1
260 mm (10.24 in)
332 mm (13.07 in)
7208 N (1621 lb)
49.9 – 51.9 mm (1.965 – 2.043 in)
260 170 mm (10.24
8.6 mm (0.339 in)
8.0 mm (0.315 in)
304 2 cm@ (47
Hydraulic
7C–33
6.70 in)
2 in@)
208RX002
