6E2–480
RODEO 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS

EVAP Canister

Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the two hoses from the EVAP canister.
3. Disconnect the fuel vapor connector and the purge
hose from the EVAP canister vent solenoid.
4. Remove the two retaining bolts the EVAP canister to
the mounting bracket on the cross member.
5. Remove the retaining bolt on the mounting bracket
the slide the canister out of mounting bracket.
014RW117
Inspection Procedure
1. Inspect the hoses for cracks and leaks.
2. Inspect the canister for a damaged case.
014RW130
014RW131
014RW129
