Removal and Installation
Refer to the Clutch Control removal and installation steps
in Clutch section.
Adjustment
1. Turn the clutch switch (1) until the switch plunger is
fully retracted against the clutch pedal arm.
2. Adjust clutch switch by backing it out half a turn and
measure the clearance (4) between the clutch pedal
arm (3) and the clutch switch.
3. Lock the lock nut(2).
4. Connect clutch switch connector.
Clutch Switch (bolt) and Clutch Pedal Clearance
0.5 – 1.5 mm (0.020 – 0.059 in)
Removal
1. Disconnect the battery ground cable.
2. Remove the rear console box assembly.
f Remove four screws.
3. Remove the cover (3).
f Remove four nuts.
4. Remove the cruise control unit (1).
f Disconnect the connector (2).
Clutch Switch
Cruise Control Unit
Installation
To install, follow the removal steps in the reverse order.
825RX017
CRUISE CONTROL SYSTEM 10A–3
203RS016–1
