EXTERIOR/INTERIOR TRIM
8J–10
General Description
The power window system consists of power window
switches and power window motors on driver and
passenger sides and power window relay. With the starter
switch in "ON" position, the battery voltage is supplied
through power window relay to the power window
switches on driver and passenger sides. Selection of up
or down switch changes the motor rotating direction to
open or close the window.
When the lock switch on the switch panel on the driver
side is pressed, the power window switch is in open state.
As a result, the power source to the other switches are cut
off, and the power window motors do not run.
Power Window Switch Driver Seat
Side
Removal
1. Disconnect the battery ground cable.
2. Remove the switch (1).
f Pull out the switch by pushing the spring with the tip
of a screwdriver.
f Disconnect the connector.
Installation
To install, follow the removal steps in the reverse order.
Front Passenger Seat Side
Removal
1. Disconnect the battery ground cable.
2. Remove the switch (1).
f Pull out the switch by pushing the spring with the tip
of a screwdriver.
f Disconnect the connector.
Power Window System
Installation
To install, follow the removal steps in the reverse order.
Rear-Left and Right Sides
Removal
1. Disconnect the battery ground cable.
2. Remove the rear door trim pad (2).
3. Remove the rear power window switch (1).
825RW080
f Refer to the Rear Door Trim Pad removal steps in
Exterior/Interior Trim section.
f Disconnect the rear power window switch (1)
connector.
f Remove the switch fixing screw from the back side
of the rear door trim (2).
825RW097
825RW081
