4. Remove the rear roof trim cover.
f Pry the trim cover clips free from the body panel.
5. Remove the rear seat belt lower anchor bolt cover
and the lower anchor bolt (5).
6. Remove the quarter trim cover (1).
f Remove the tool box lid (3) and 3 fixing screws (4).
Pry the quarter trim cover retainers (2) free from the
body panel.
General Description
The system consists of the starter switch, door mirror
switch, rear defogger/mirror defogger switch and door
mirrors on both sides.
When the door mirror switch is operated with the starter
switch at either "ACC" or "ON" position, the motor in the
door mirror (on either side) rotates to allow the horizontal
and vertical adjustment of mirror angles.
When the rear defogger/mirror defogger switch is turned
"ON" (with the starter switch at "ON" position), the heaters
in both left and right mirrors and the rear windshield glass
are active defog both mirrors and rear windshield glass at
the same time.
Door Mirror Switch
Removal
1. Disconnect the battery ground cable.
2. Remove the instrument panel lower cover (2).
Refer to the instrument panel assembly in Body
Structure section.
3. Remove the door mirror switch (1).
643RW001
Power Door Mirror System
EXTERIOR/INTERIOR TRIM
7. Remove the center lower trim cover.
f Remove the front seat belt lower anchor bolt cover
and lower anchor bolt.
f Remove the sill plate and pry the trim cover clips
free from the body panel.
8. Remove the center upper trim cover.
f Turn up the finisher and pry the trim cover clips free
from the body panel.
9. Remove the front pillar trim cover
f Turn up the finisher and pry the trim cover clips free
from the body panel.
Installation
To install, follow the removal steps in the reverse order,
noting the following point:
1. Tighten the seat belt anchor bolt to the specified
torque.
Torque: 39 N·m (29 lb ft)
Rear Defogger/Mirror Defogger Switch
Refer to the Rear Defogger/Mirror switch removal and
installation steps in Lighting System section.
Door Mirrors
Refer to the Door mirrors removal and installation steps in
Exterior/Interior Trim section.
8J–9
825RW094
