Chart A SDM Integrity Check
WARNING: DURING SERVICE PROCEDURES. BE VERY CAREFUL WHEN HANDLING A SENSING AND
DIAGNOSTIC MODULE (SDM). NEVER STRIKE OR JAR THE SDM. NEVER POWER UP THE SRS WHEN THE
SDM IS NOT RIGIDLY ATTACHED TO THE VEHICLE. ALL SDM AND MOUNTING BRACKET FASTENERS MUST
BE CAREFULLY TORQUED AND THE ARROW MUST BE POINTING TOWARD THE FRONT OF THE VEHICLE
TO ENSURE PROPER OPERATION OF THE SRS. THE SDM COULD BE ACTIVATED WHEN POWERED WHILE
NOT RIGIDLY ATTACHED TO THE VEHICLE WHICH COULD CAUSE DEPLOYMENT AND RESULT IN
PERSONAL INJURY.
Step
1 1. This chart assumes that the "SRS Diagnostic System Check"
and either a symptom chart or a diagnostic trouble code chart
diagnosis have been performed When all circuitry outside the
SDM has been found to operate properly, as indicated by the
appropriate diagnostic chart, and the symptom or DTC
remains current, the following diagnostic procedures must be
performed to verify the need for SDM Replacement.
2. Ignition switch "OFF."
3. Reconnect all SRS components, ensure all components are
properly mounted.
4. Ensure the ignition switch has been "OFF" for at least 15
seconds.
5. Note "AIR BAG" warning lamp as ignition switch is turned
"ON."
Does warning lamp flash 7 times then go "OFF"?
2 Using a scan tool, request diagnostic trouble code display.
Is the same symptom or DTC occurring as was when the "SRS
Diagnostic System Check " was first performed?
3 1. Clear "SRS Diagnostic Trouble Codes."
2. Ignition switch "OFF" for at least two minutes.
3. Note "AIR BAG" warning lamp as ignition switch is turned
"ON."
Does warning lamp flash 7 times then go "OFF"?
4 Reconnect all SRS components, ensure all components are
properly mounted.
Was this step finished?
Action
RESTRAINT CONTROL SYSTEM
Yes
The symptom or
DTC is no longer
occurring.
Clear SRS
diagnostic trouble
codes.
Repeat the "SRS
Diagnostic
System Check."
Ignition switch
"OFF."
Go to the
appropriate chart
for the indicated
malfunction.
SRS is functional
and free of
malfunctions.
No further
diagnosis is
required.
Go to Step 4
Repeat the "SRS
Diagnostic
System Check."
9J1–7
No
Go to Step 2
Go to Step 3
Ignition switch
"OFF."
Replace SDM.
Go to Step 4
Go to Step 4
