Removal
1. Disconnect the battery ground cable.
2. Remove the sun roof drive unit assembly (1) to
remove the limit switch (2).
Refer to the Sun Roof Frame Complete Assembly
disassembly steps in this section.
Removal
1. Disconnect the battery ground cable.
2. Remove the headlining (2).
Refer to the Headlining removal steps in
Exterior/Interior Trim section.
3. Remove the sun roof motor (1).
f Disconnect the connector.
f Remove three nuts and two screws.
SUN ROOF/CONVERTIBLE TOP
Limit Switch
Installation
To install, follow the removal steps in the reverse order.
665RS025
Sun Roof Motor
Installation
To install, follow the removal steps in the reverse order.
665RW014
8I–9
